Motor controls

Easy adjustable controllers for brushed and brushless dc motors.



M2-MR-5-30 (06.34.001) Nominal current : 5 A

Characteristics

rotation reversal
speed control
start ramp
dynamic brake
analog input
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.34.001_M2-MR-5-30_en.pdf

M3-4Q-5-30 (06.34.002) Nominal current : 5 A

Characteristics

rotation reversal
speed control
IxR compensation
start ramp
dynamic brake
overcurrent limitation
overcurrent shutdown
manual adjustment elements
analog input
push-in terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.34.002_M3-4Q-5-30_en.pdf

M3-2QB-5-12 (06.34.006) Nominal current : 5 A

Characteristics

rotation reversal
speed control
start ramp
stop ramp
dynamic brake
overcurrent limitation
overcurrent shutdown
manual adjustment elements
analog input
push-in terminals

Voltage

12 VDC

Motor

DC Motor

datasheet

06.34.006_M3-2QB-5-12_en.pdf

M2-MWT-6-30 (06.34.007) Nominal current : 6 A

Characteristics

rotation reversal
dynamic brake
overcurrent shutdown
manual adjustment elements
push-in terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.34.007_M2-MWT-6-30_en.pdf

M2-MWI-6-30 (06.34.008) Nominal current : 6 A

Characteristics

rotation reversal
dynamic brake
overcurrent shutdown
manual adjustment elements
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.34.008_M2-MWI-6-30_en.pdf

M3-2QB-5-30 (06.34.010) Nominal current : 5 A

Characteristics

rotation reversal
speed control
start ramp
stop ramp
dynamic brake
overcurrent limitation
overcurrent shutdown
manual adjustment elements
analog input
push-in terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.34.010_M3-2QB-5-30_en.pdf

Maxi-M-8-30 (06.04.001) Nominal current : 8 A

Characteristics

dynamic brake
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.001_Maxi-M-8-30_en.pdf

Maxi-MW-8-30 (06.04.002) Nominal current : 8 A

Characteristics

rotation reversal
dynamic brake
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.002_Maxi-MW-8-30_en.pdf

Maxi-S-4-30 (06.04.007) Nominal current : 4 A

Soft braking via external braking resistor

Characteristics

start ramp
dynamic brake
manual adjustment elements
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.007_Maxi-S-4-30_en.pdf

M-S-6-30 (06.04.008) Nominal current : 6 A

Characteristics

speed control
start ramp
stop ramp
dynamic brake
manual adjustment elements
analog input
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.008_M-S-6-30_en.pdf

Midi-M-8-30 (06.04.012) Nominal current : 8 A

Characteristics

screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.012_Midi-M-8-30_en.pdf

Maxi-MW-8-12 (06.04.014) Nominal current : 8 A

Illustration similar

Characteristics

rotation reversal
dynamic brake
screw terminals

Voltage

12 VDC

Motor

DC Motor

datasheet

06.04.014_Maxi-MW-8-12_en.pdf

Maxi-MR-5-30 (06.04.016) Nominal current : 6 A

This product is no longer available. Possible replacement:: 06.34.001

Characteristics

rotation reversal
speed control
start ramp
dynamic brake
analog input
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.016_Maxi-MR-5-30_en.pdf

Maxi-MR-5-12 (06.04.019) Nominal current : 5 A

This product is no longer available. Possible replacement:: 06.34.006

Characteristics

rotation reversal
speed control
start ramp
dynamic brake
analog input
screw terminals

Voltage

12 VDC

Motor

DC Motor

datasheet

06.04.019_Maxi-MR-5-12_en.pdf

M-2Q-6-30 (06.04.021) Nominal current : 6 A

Characteristics

speed control
dynamic brake
overcurrent limitation
manual adjustment elements
analog input
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.021_M-2Q-6-30_en.pdf

M-MWI-5-30 (06.04.025) Nominal current : 5 A

Not recommended for new designs. Possible replacement: 06.34.008

Characteristics

rotation reversal
dynamic brake
overcurrent shutdown
manual adjustment elements
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.025_M-MWI-5-30_en.pdf

M-4Q-6-30 (06.04.031) Nominal current : 6 A

+- 10 V analog input

Not recommended for new designs. Possible replacement: 06.34.002

Characteristics

rotation reversal
speed control
IxR compensation
dynamic brake
overcurrent limitation
manual adjustment elements
analog input
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.031_M-4Q-6-30_en.pdf

M-4Q-6-48 (06.04.032) Nominal current : 6 A

Illustration similar

+- 10 V analog input

Characteristics

rotation reversal
speed control
IxR compensation
dynamic brake
overcurrent limitation
manual adjustment elements
analog input
screw terminals

Voltage

48 VDC

Motor

DC Motor

datasheet

06.04.032_M-4Q-6-48_en.pdf

M-1Q-6-30 (06.04.039) Nominal current : 6 A

Characteristics

speed control
IxR compensation
dynamic brake
manual adjustment elements
analog input
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.039_M-1Q-6-30_en.pdf

M-MWI-5-12 (06.04.046) Nominal current : 5 A

Illustration similar

Not recommended for new designs. Possible replacement: 06.34.006

Characteristics

rotation reversal
dynamic brake
overcurrent shutdown
manual adjustment elements
screw terminals

Voltage

12 VDC

Motor

DC Motor

datasheet

06.04.046_M-MWI-5-12_en.pdf

Maxi-1Q-4-30 (06.04.048) Nominal current : 3,5 A

Characteristics

speed control
IxR compensation
dynamic brake
manual adjustment elements
analog input
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.048_Maxi-1Q-4-30_en.pdf

M-MWI-1-30 (06.04.049) Nominal current : 1 A

Illustration similar

Not recommended for new designs. Possible replacement: 06.34.008

Characteristics

rotation reversal
dynamic brake
overcurrent shutdown
manual adjustment elements
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.049_M-MWI-1-30_en.pdf

M-MZ-4-30 (06.04.051) Nominal current : 3 A

Characteristics

rotation reversal
speed control
dynamic brake
manual adjustment elements
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.051_M-MZ-4-30_en.pdf

M-BL-5-30 (06.04.054) Nominal current : 3,5 A

Characteristics

rotation reversal
speed control
dynamic brake
overcurrent limitation
manual adjustment elements
analog input
push-in terminals

Voltage

24 VDC

Motor

BLDC Motor

datasheet

06.04.054_M-BL-5-30_en.pdf

M-MRI-3-30 (06.04.056) Nominal current : 3 A

Characteristics

rotation reversal
speed control
dynamic brake
overcurrent shutdown
manual adjustment elements
analog input
push-in terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.056_M-MRI-3-30_en.pdf

M-1Q-5-30 (06.04.059) Nominal current : 5 A

Characteristics

rotation reversal
speed control
IxR compensation
dynamic brake
manual adjustment elements
analog input
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.059_M-1Q-5-30_en.pdf

M-BL-10-24 (06.04.066) Nominal current : 10 A

Characteristics

rotation reversal
speed control
dynamic brake
overcurrent shutdown
manual adjustment elements
analog input
screw terminals

Voltage

24 VDC

Motor

BLDC Motor

datasheet

06.04.066_M-BL-10-24_en.pdf

M-4Q-10-30 (06.04.075) Nominal current : 10 A

Characteristics

rotation reversal
speed control
IxR compensation
start ramp
dynamic brake
overcurrent limitation
overcurrent shutdown
manual adjustment elements
analog input
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.075_M-4Q-10-30_en.pdf

M-MWS-6-30 (06.04.078) Nominal current : 6 A

Characteristics

rotation reversal
dynamic brake
push-in terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.078_M-MWS-6-30_en.pdf

M-4Q-10-48 (06.04.083) Nominal current : 10 A

Illustration similar

Characteristics

rotation reversal
speed control
IxR compensation
start ramp
dynamic brake
overcurrent limitation
overcurrent shutdown
manual adjustment elements
analog input
screw terminals

Voltage

48 VDC

Motor

DC Motor

datasheet

06.04.083_M-4Q-10-48_en.pdf

M-4Q-5-30 (06.04.085) Nominal current : 5 A

Not recommended for new designs. Possible replacement: 06.34.002

Characteristics

rotation reversal
speed control
IxR compensation
start ramp
dynamic brake
overcurrent limitation
overcurrent shutdown
manual adjustment elements
analog input
screw terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.085_M-4Q-5-30_en.pdf

M-RA-5-24 (06.04.093) Nominal current : 5 A

Characteristics

rotation reversal
speed control
IxR compensation
start ramp
stop ramp
dynamic brake
manual adjustment elements
analog input
push-in terminals

Voltage

24 VDC

Motor

DC Motor

datasheet

06.04.093_M-RA-5-24_en.pdf
